Xtreme 8.5
The MTF Xtreme 8.5 is a full-suspension SUV e-bike that blends the agility of a mountain bike with the comfort and utility of a touring model. With 29” wheels, wide Maxxis Forekaster 2.4” tires, and a powerful Bafang M510 mid-drive motor, it's built for both off-road trails and long-distance rides. Integrated fenders, a rear rack, and advanced suspension ensure maximum comfort and control wherever you ride.

The MTF Xtreme 8.5 is a premium full-suspension SUV e-bike that merges the versatility of a mountain bike with the features of a touring model, making it ideal for both rugged off-road terrain and extended bike path adventures. Designed with a mountain bike geometry, integrated fenders, a rear carrier, and wide Maxxis Forekaster 29.5 x 2.4" tires on 29" wheels, it offers a perfect balance between performance and practicality.
At its core is the powerful Bafang M510 mid-drive motor with a pressure sensor – currently the most powerful in its class. Delivering up to 95 Nm of torque and 750 W of peak output, it ensures smooth and efficient power, whether you're climbing steep hills or cruising on pavement.
This model is equipped with high-end components to tackle tough conditions. A Shimano CUES 11-speed shifter and CUES RD-U6000GS derailleur provide precise shifting, while the SR Suntour XCR BOOST AIR fork with 140 mm travel and the RAIDON LO AIR rear shock (190 x 51 mm) offer excellent suspension performance. Shimano BR-MT410 hydraulic disc brakes deliver dependable stopping power even on challenging descents, and the drivetrain is complemented by a Shimano CUES 11-speed cassette (11–50T) and Shimano chain (CN-LG500).
.jpg)

Riding comfort is further enhanced by aluminum pedals with ball bearings, offering a solid grip and smooth rotation – ideal for longer rides and variable terrain.
Available in 19” and 21” frame sizes, the reinforced aluminum frame (Alu 6061) supports riders up to 140 kg, with reinforced steel spokes for added durability.
All riding data, assistance levels (5 modes), and battery status are clearly displayed on a color smart LCD with Bluetooth and GPS capabilities.
The integrated battery with Samsung cells comes in multiple capacities, with the most powerful 24.5 Ah version (882 Wh) delivering a range of up to 200 km on a single charge.
Frame & Suspension:
-
Frame: Alu 6061
-
Frame size: size 19" (4KOE25024), 21" (4KOE25025)
-
Fork: Air SR Suntour XCR BOOST AIR, 140 mm stroke, lockable
-
Rear Shock absorber: RAIDON LO AIR, 190 x 51 mm
Motor & Battery:
-
Motor: BAFANG M510 250W/max.750W, centre motor with pressure sensor, 95 N.m
-
Battery: AKU battery 24,5 Ah (882 Wh) (SMART 3pin) (4KOZ6071)
-
Speed: Assisted up to 25km/h
Drivetrain:
-
Crankarm: BAFANG (38 teeth), handle length 170 mm
-
Shifter: Shimano CUES SL-U600011RC, 11 speeds
-
Rear Derailleur: SHIMANO CUES RD-U6000GS 10/11s
-
Front Derailleur: SHIMANO Tourney FD-TZ510
-
Cassette: Shimano CUES CS-LG400 11spd, 11-50T
Free:
-
Stand
TECHNICAL SPECIFICATION
Wheels & Tires:
-
Brakes: Shimano BR-MT410 Hydraulic Disc
-
Front Hub: NOVATEC D041
-
Rear Hub: NOVATEC D442SB
-
Rims: STARS CIRCLE, 36H
-
Tires: MAXXIS FOREKASTER 29.5*2.4
-
Wheels: 29"
Components:
-
Display: Colour LCD Smart Display, 5 levels of assistance
-
Handlebars: MTF Sport (31.8/760 mm)
-
Stem: MTF Sport (31.8, length 60 mm)
-
Seatpost: MTF (30.9 mm / 400 mm)
-
Saddle: Selle Royal
-
Grips: MTF SportGrip
Weight & Capacity:
-
Weight: 21 kg
-
Load Capacity: 140 kg
Battery
